IP67 ODVA LC to LC Duplex Fiber Optic Patch Cable

  • PRODUCT NAME:

  • IP67 ODVA LC to LC Duplex Fiber Optic Patch Cable

  • ART NO:

  • IP67 ODVA LC to LC Duplex

  • Description:

  • LC to LC Duplex ODVA IP67 Fiber Optic Patch Cable
    • Sealed Circular IP 67 ODVA Duplex LC fiber patch cable assemblies are available in both single-mode and multimode version, this ODVA LC is a typical outdoor use fiber cable, suitable for different temperature and weather, especially ideal for FTTA and harsh environment use. our IP 67 ODVA LC duplex cables are designed as per IEC 61076-3-106 interfaces standard, integrated with our quality LC fiber connectors with loss optical loss; and we designed a rugged and armored PE jacketed optical cable body. we have these ODVA LC in 9/125 LC/UPC, 50/125 OM2/OM3/OM4/OM5 LC/UPC and 62.5/125 OM1 LC/UPC. cable assemblies can be custom made in ODVA Duplex LC to Breakout dual LC, or ODVA LC to other popular connectors.
    Specifications:

    Parameters
    LC/PC
    LC/UPC
    LC/APC
    Working Temperature (°C)
    -40 — +80
    Insertion Loss (dB)
    ≤0.2
    ≤0.2
    ≤0.2
    Return Loss( dB)
    ≥45
    ≥50
    ≥60
    Tensile strength(N)
    ≥55
    ≥55
    ≥55
    Durability(Times)
    Exert a force of 1N for 1 hour at a
    distance of 0.5meter from the rear of the connector.

    Apply To: Gigabit Ethernet and Fiber Channel applications, Ideal solution for data applications requiring high-speed data transmission; Broadband systems; Telecommunication/Data communication; widely used in FTTA & FTTH; Used for the 3G 4G base station; BBU, RRU, RRH, LTE
    Feature:
    1. Standard Duplex LC connector, well connected with standard LC interface
    2. Available in Single-mode and Multimode
    3. IP67 protection, salt-mist proof, humidity-proof, dustproof
    4. Low insertion loss, steady optical transmitting
