EMI/EMC FILTER 250V 10A

  • PRODUCT NAME:

  • EMI/EMC FILTER 250V 10A

  • ART NO:

  • EMIF10A

  • Description:

  • Features:
    • High-quality miniature emi/emc filter with metal case.
    • IEC connector meets the safety standards.
    • Faston tab type
    • UL, CSA, TÜV, SEMKO, NEMKO and FIMKO approved.
    • Meets overvoltage category II of IEC664 and complies with IEC950.
    • Can be used in digital equipment, PCs and peripheral equipment, measuring instruments, monitor and display units.
    Specifications:
    • Rated voltage: 250Vac
    • Rated current: 10A
    • Leakage current: 0.35mA max.
    • Fast-on connections
    • Insulation resistance: 100Mohm min. @ 250Vdc
    • Direct current resistance: 0.2 ohm max.
    • Weight: 45g
    • Operating temperature: -25°C to +85°C
    • Cx: 0.1µF
    • Cy: 2 x 3.3nF
